ProSource C501-AB-SA-AS Door Closer, Non-Handed Hand, Automatic, Aluminum, Silver, 240 lb

ProSource

ProSource C501-AB-SA-AS Door Closer, Non-Handed Hand, Automatic, Aluminum, Silver, 240 lb

$87.69$87.69
ProSource C501-AB-SA-AS Door Closer, Non-Handed Hand, Automatic, Aluminum, Silver, 240 lb
  • Arm Material: Steel
  • Arm Type: Parallel Arm
  • Automatic/Manual: Automatic
  • Color: Silver
  • Finish: Silver
  • Model #: C501-AB-SA-AS
  • UPC #: 050134901339
  • SKU: 6067946

Your shopping list will be used for pickup in-store

Product Details

The ProSource door closer has an aluminum casted body with steel arm to resist corrosion. It's steel rack and pinion is heat treated for smooth action and minimum wear. The closer is lubricated with stable hydraulic fluid for multi-climate operation. It has an adjustable back check, fits left handed or right handed installations, does not have hold-open feature and the power size is 1-4. This product is ADA compliant and it comes boxed.

Key Features

  • Independent adjustable back check, closing & latching valves
  • Full 180 degree door swing
  • Universal arm assembly for all applications
  • The door closer is ANSI grade 1
  • Adjustable size is #1-4

Item Specifications

Arm MaterialSteel
Arm TypeParallel Arm
Automatic/ManualAutomatic
ColorSilver
FinishSilver
Hand OrientationNon-Handed
Height8.5 in
Housing Length210 mm
IncludesPA Bracket
MaterialAluminum
Mounting Hole Distance230 x 19 mm
Mounting Hole Size7 mm
Mounting TypeRegular Parallel Arm Top Jamb
Spring Size1 to 4
Weight Capacity240 lb
